LCD Video Wall Rentals (60″ Sharp PN-V602)
This Video Wall display features the world’s slimmest bezel available on a 60″ monitor with a full-array LED backlight. It delivers brightness up to 1500 cd/m2, making it suitable for semi-outdoor environments.
Product Weight: 110 lbs
Dimensions: 52.63″W x 5.88″D x 29.69″H
Description
The monitor features a native resolution of 1366 x 768 from analog RGB, digital RGB and HDTV video sources. When used in a 3×3 video wall display, it provides over 4K x 2K total resolution (4098 x 2304 pixels) for ultra-high resolution and ultra-high-impact images.
An Enlarge (Zoom) Display mode enables one image to be spread across up to 25 monitors (in up to a 5×5 configuration). The Frame Width Adjustment function eliminates misalignment and helps enhance the enlarged image in a multi-screen display.
The PN-V602 is compatible with third-party video wall processors, facilitating the creation of video walls of virtually unlimited size and configuration.
General
Screen Size: 60″ Diagonal
Bezel Width
Right/bottom: 2.4 mm
Left/top: 4.1 mm
Native Display Resolution: 1366 x 768
Maximum Brightness (average): 1,500 cd/m2
Landscape and Portrait Mode Operation: Yes
Certified for 24/7 Continuous Operation: Yes
Fanless Architecture: No
Audio: 10W + 10W Stereo with built in speakers
LCD Type: UV2A LCD
Number of Colors (approx.): 16.77 Million
Contrast Ratio: Up to 1,000,000 (local dimming set to HIGH); Up to 5,000:1 (local dimming OFF)
Aspect Ratio: 16:9
Viewing Angle (H/V): 176º H x 176º V (CR>/=10)
Active Screen Area (approx.): 52.31″W x 29.44″H
Frame Rate: 60 Hz
Pixel Pitch: 0.485 mm H x 0.485 V
Video System: NTSC (3.58 MHz; 4.43 MHz), PAL, PAL60, SECAM
Computer Inputs
Video: Analog RGB (0.7 Vp-p) [75-ohm], Digital (conforms to DVI 1.0 standards)
Synchronization: Horizontal / Vertical separation (TTL: positive/negative), Sync on green, composite sync (TTL: positive/negative)
Plug & Play: VESA DDC2B
Power Management: VESA DPMS, DVI DMPM
Response Time: 6ms (gray to gray, average)
Terminals
PC/AV Video Input:
Analog mini D-Sub 15-pin
DVI-D 24-pin HDCP Compatible (requires optional PN-ZB01)
Analog 5-BNC (requires optional PN-ZB01; analog RGB and component are menu selectable).
PC/AV Audio Input: 3.5 mm mini stereo jack
Video Input
Composite Video: BNC (requires optional PN-ZB01)
S-Video Input: 5-Pin DIN (requires optional PN-ZB01)
Component Video: BNC (Y, Cb/Pb,Cr/Pr) (requires optional PN-ZB01; component video and analog RGB are menu selectable).
HDMI®: Yes – compatible for both PC and AV components
Tuner: None
Audio (AV): RCA pin (L/R) x 2 (requires optional PN-ZB01)
Computer Output: DVI-D 24-pin (HDCP compatible, PC/AV signal; requires optional PN-ZB01)
Audio Line Output: RCA pin (L/R) – selectable fixed or variable line output
Speaker Output: 10W + 10W Stereo (6Ω; requires optional PN-ZB01)
LAN Port: RJ-45 (requires optional PN-ZB01)
RS-232C: D-sub 9-pin
Remote Control
Wireless remote control included.
Optional PN-ZR01 Control Kit (remote controller and remote control sensor box).
Also available: wired RJ-45 and RS-232C (RJ-45 requires optional PN-ZB01)
Functions
Screen Adjustment: Auto (Clock, Phase, H-POS/V-POS) / Manual
Gain Control: Auto (Black level, Contrast) / Manual
Digital Scaling (expansion): Yes (VGA/SVGA/XGA/SXGA -> 1366 x 768)
Digital Scaling (compression): 1920 x 1200, 1920 x 1080, 1600 x 1200, 1280 x 1024
Main User Adjustments: Clock, Phase, H-POS/V-POS, Black level, Contrast; Color temp (15 steps preset + 5600K/9300K + User setting); Color mode (Standard/sRGB/Vivid); Gamma (1.8/2.0/2.2/2.4/User setting); Brightness, Volume, Audio (Treble/Bass/Balance), OSD-POS; Picture Adjustment (Tint, Color Intensity) [PC/AV mode]; R/G/B/Y/M/C independent adjustment [AV mode]
Information: Model No., Serial No. etc.
Real Time Clock Setting: Yes
Scheduling Function: Yes (time, day of the week)
All Reset: Yes
Reset: Screen/Picture/Audio adjustment setting, etc.
Adjustment Lock: YES (incl. Power button)
Daisy Chain (DVI-D): Optional (PN-ZB02): max. 5 units (HDCP compliant). (Splitter required for more than 6 units.)
Enlarge: Yes (Up to 5×5)
Frame Width Adjustment: Yes
PinP / PbyP: Yes (PinP -12 steps)
Power On Delay: 1-60 seconds (with 1 second interval)
Audio Input Change: Yes
Picture Flip: No
Self Adjust: Yes (PC Analog Input)
Log Save / Output: Yes
Temperature Control: Yes
Hardware Diagnosis: Yes
Monitor Control Software Support: Yes
Web Browser Setting (LAN): Optional (PN-ZB02)
E-Mail Notification: Optional (PN-ZB02)
SNMP: Optional (PN-ZB02)
Overscan Setting (AV Input): Yes
Image Size Change Function: Yes
Resolution Change Function (PC analog): Yes
RS-232C Communication Speed Change: Yes
Conversion of Stereo Audio to Monaural: No
Selection of Audio Input per image input: Yes
Internal / External Speaker Select: No. External Only (with Optional PN-ZB02)
Compatibility with Sharp Digital Signage Software (SDSS, optional): Yes. SDSS software delivers content program creation, registration, scheduling and distribution of pre-scheduled information on Sharp PN series displays. Operates easily with user-friendly interface.
Power
Source: 100 – 240 VAC, 50/60 Hz
Consumption
Operation: 510W Max. (Local dimming off)
Standby: 1W (standby mode in Standard), 0.5W (standby mode in Low Power)
Physical
Dimensions: 52.63″W x 5.88″D x 29.69″H (1335.9 x 149.3 x 754.2 mm)
Weight: 110 lbs (55 kg) approx.
Mounting Configuration: VESA (6 points), 200 mm (7.88″) pitch, M6 screws or VESA (4 points), 200 mm (7.88″) pitch, M6 screw
Environmental
Temperature
Operating: 32° to 104°F (0° to 40°C)
Storage: -4° to 140°F (-20° to +60°C)
Operating Humidity: 20% to 80% RH (no condensation)
Certifications
Regulatory Approvals: UL 60950, FCC Class A
ENERGY STAR® Qualified: Yes
Included Accessories
3-wire (grounded) power cord (approx. 10′)
Remote control with batteries (AA x 2)
CD-ROM, operation manual
Stand hole protection cover x 2
Vertical sticker (operation panel)
Vertical sticker (logo)
Blank sticker
Cable clamp x 2
Optional Input/Output Interface Board: PN-ZB02
UPC: 074000047044
Easily attaches to rear of display and adds
DVI-D input/output
Analog RGB inputs (BNC x 5)
Composite video input
Component video input
S-video input
Stereo audio (RCA) input x 2
RJ-45 LAN display control
Stereo speaker output (10W x 2, 6-ohms).
